Metallic Tape – Innovative Gas Leak Repair Tape
Overview
This tape comprises a lead sheet (0.4mm) known for its exceptional tactile resistance and formability. This sheet is laminated with a high-adhesive layer (0.8mm), primarily made of butyl rubber. By removing the release paper and wrapping this anti-corrosion tape around the corroded hole (combined with a protective tape), gas leaks can be effectively sealed.
Features
Anti-Corrosion
Both Santac Roof 6 & 7 tapes and metallic tapes provide excellent insulation resistance, chemical resistance, and water tightness. The adhesive layer adheres strongly to corroded pipes. Once repaired, it shields the pipe from external corrosive environments, ensuring superior anti-corrosion performance.
Applicable to Complex Joints
The metal tape, which uses a lead plate for reinforcing corroded pipes, fits well onto complex joints such as sockets and screw parts. Moreover, the Santac Roof 6-7 tape has a reinforcement rubber sheet that’s flexible and made of non-vulcanized rubber, making it easy to relieve stress. It adheres well to the wrapping section, fits onto uneven surfaces, and can easily be applied to complex joints without the need for a specialist.
Excellent Pressure and Impact Resistance.
The metallic tape provides significant resistance against external impacts, soil pressure, and internal pressures, due to the synergy of various materials, including lead sheets.
No Flame Required
Safe for gas leak point repairs since no flame is involved.
How to Use
1. Surface Preparation
Temporarily seal the corrosion hole or leak area with putty or tape. Clean an area spanning approximately 20 cm before and after the leak with tools like a wire brush, removing any anti-corrosion tape, soil, sand, mud, and loose rust attached to the pipe. Dry the area and ensure the pipe surface is exposed.
2. Wrapping with Metal Tape or Anti-corrosion Rubber Tape
- Before wrapping with the metal tape, attach a thin polyester film tape over the corrosion hole, removing any putty. The length of the tape should be determined so that the adhesive overlap around the corroded area is at least 1 cm.
- Over the thin film tape, wrap the metal tape around once, like rolling a cigarette. When wrapping the metal tape, start on the side opposite the corrosion hole and ensure at least a 30mm overlap.
- After wrapping with the metal tape, press firmly using a hand roller or equivalent. Pay particular attention to pressing thoroughly at the overlapped area and any level differences.
- When starting to wrap with the Santac Roof 6 & 7 tape, wrap the width of the tape around once. In the middle, use a half wrap per round, and finish similarly by wrapping the tape’s width around once at the end.
3. Wrapping with Protective Tape
Wrap the Anti-corrosion Green Tape with a half overlap for each round over the Anti-corrosion Rubber Tape or Sheet.
Specification
Performance
- Lead plate: JIS H 4501 (1955)
- Adhesive Layer:
| Item | Unit | Standard | Actual | Test Method |
|---|---|---|---|---|
| Color | - | Black | black | Visual |
| Density | mg/m^3 | 1.35+-0.1 | 1.35 | JIS K 6268 |
| Degree of Penetration | - | 115+-15 | 115 | JIS K 2207 (20℃) |
| Steel Surface Adhesion | N/25mm | More than 15 | 28 | Loading 100g/cm² x 30 min pressure / A 180-degree peel test & peeling speed 300mm/min |
| Temperature | - | No error | No error | JIS K 6380 (-40℃) |
| Volume Resistivity | Ω - cm | More than 10^12 | 1.5x10^15 | JIS K 6911 |
| Absorption Rate | % | less than 0.5 | 0.1 | JIS K 6258 / Soaking for 4 days and leaving for 1 hour with room temperature |
Materials
Repair Tape: Metallic Tape
- Stiffener Material: Lead plate
- Thickness: 0.3mm
- Width: 40mm
- Adhesive Layer Material: Butyl rubber
- Thickness: 0.8mm
- Width: 50mm
- Length: 5m
- Purpose: To use for covering external surface with anti-corrosion tape
Anti-Corrosion Tape: Santac Roof 6・7 Tape
- Material: Non-vulcanized rubber sheet (Butyl Rubber)
- Adhesive Layer Material: Butyl rubber
- Width: 50mm and 100mm
- Thickness: 1.3mm
- Length: 5m
- Purpose: To use for protecting the metallic tape
Protective Tape: Anti-Corrosion Green Tape
- Material: Polyvinyl chloride
- Adhesive Layer Material: Butyl rubber
- Width: 50mm and 100mm
- Thickness: 0.4mm
- Length: 10m
- Purpose: To use for covering external surface with anti-corrosion tape
Sealing Tape: Thin Film Tape
- Material: Polyester film
- Adhesive Layer Material: Butyl rubber
- Width: 50mm
- Thickness: 0.4mm
- Length: 10m
- Purpose: To use for correction of the unevenness of the corroded surface and metallic tapes’s base
